Gniazdo procesora: Socket 1851
Obsługiwane typy procesorów: Intel Core Ultra Processors (series 2)
Format płyty: ATX
Chipset płyty głównej: Intel® Z890
Ilość złącz pamięci DDR5: 4
Maksymalna wielkość pamięci: 256 GB
Tryb pracy pamięci RAM: Dual Channel
Uwagi do pamięci RAM: Max. overclocking frequency:, - 1DPC 1R Max speed up to 9200+ MT/s, - 1DPC 2R Max speed up to 7200+ MT/s, - 2DPC 1R Max speed up to 4800+ MT/s, - 2DPC 2R Max speed up to 4800+ MT/s, Supports Intel POR Speed and JEDEC Speed, Supports Memory Overclocking and Intel XMP 3.0, Supports Dual-Controller Dual-Channel mode, Supports Non-ECC, Un-buffered memory, Supports CUDIMM, Memory Support 9200 - 6400 (OC) MT/s / 6400 - 4800 (JEDEC) MT/s
Zintegrowany kontroler SATA: Chipset+CPU: 4x SATA III 6Gb/s + 5x M.2
Uwagi do kontrolera SATA: - M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 ,, supports 2280/2260 devices, - M.2_2 Source (From CPU) supports up to PCIe 4.0 x4 ,, supports 2280/2260 devices, - M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 ,, supports 2280/2260 devices, - M.2_4 Source (From Chipset) supports up to PCIe 4.0 x4 ,, supports 22110/2280 devices, - M.2_5 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode,, supports 2280/2260 devices, M2_4 default from chipset, can support PCIe 5.0 x4 (From CPU) by manual, BIOS adjustment
Gniazda karty graficznej: HDMI, 2x Thunderbolt™ 4 (USB Type-C®)
Uwagi do karty graficznej: Support HDMITM 2.1 with FRL port, maximum resolution of 8K 60Hz, Thundebolt 4 ports supporting DisplayPort 1.4 with HBR3 over USB Type-C,, with a maximum resolution of 8K@60Hz, Graphics specifications may vary depending on the CPU installed
Zintegrowana karta dźwiękowa: Realtek® ALC4082 Codec + ESS9219Q Combo DAC/HPA
Gniazda karty dźwiękowej: Wewnętrzne gniazdo audio przedniego panelu, 2x Audio Jack, Wyjście optyczne S/PDIF
Uwagi do karty dźwiękowej: Supports up to 32-Bit/384 kHz playback on front panel
Złącza PCI Express x16: 3
Uwagi do złącz PCI: - PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU), - PCI_E2 Gen PCIe 5.0 supports up to x8 (From CPU), - PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset), - PCI_E1 support manual BIOS adjustment to X8+X8/X8+X4+X4, - PCI_E2 support manual BIOS adjustment to X4+X4, - PCI_E1 slot will run at x8 speed when PCI_E2 slot installing device, - PCI_E1 slot will run at x8 speed and PCI_E2 slot will run at x4 speed, when installing PCIe Gen 5 M.2 device in the M2_4 slot
Port LAN: 1x 10 Gigabit LAN Marvell® AQC113CS
Maksymalna ilość portów USB 2.0: 4
Maksymalna ilość portów USB 3.x: 18
Porty USB na panelu tylnym: 11x USB 3.1 + 2x USB 3.1 Type-C
Gniazda USB na płycie głównej: 2x USB 2.0 (2 porty) + 2x USB 3.0 (4 porty) + 1x USB 3.2 Type-C (1 port)
Port Wi-Fi: IEEE 802.11a/b/g/n/ac/ax/be
Port Bluetooth: Bluetooth V5.4
Uwagi do WiFi / BT: Intel® Killer™ BE1750x Wi-Fi 7, The Wireless module is pre-installed in the M.2 (Key-E) slot, Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (320MHz) up to 5.8Gbps, Supports 802.11 a/ b/ g/ n/ ac/ ax/ be, Supports Bluetooth® 5.4**, MLO, 4KQAM, 6GHz band support may depend on every country's regulations and Wi-Fi 7, will be ready in Windows 11 version 24H2, The Bluetooth version may be updated, please refer to the Wi-Fi chipset, vendor's website for details. Bluetooth 5.4 will be ready in Windows 11, version 24H2
Port PS/2: Brak
Port szeregowy (COM): Brak
Port równoległy (LPT): Brak
Inne porty i gniazda: Thunderbolt 5 card connector(JTBT5, support RTD3), Front Type-C Quick Charge Connector(PD_PWR1), 2x Combo Fan (Pump_Sys Fan), 5x System Fan, EZ Conn-header (JAF_2), 2x Front Panel, Chassis Intrusion (JCI), Water Flow connector, Slow mode booting jumper, 2x Thermal Sensor connectors, Tuning Controller Connector, 3x Addressable V2 RGB LED connector, RGB LED connector, Gniazdo modułu TPM, V-check point, Clear CMOS button(s)
Wymiary [S x W] (mm): 243,84 x 304,8
Opakowanie: BOX
Zawiera baterię / akumulator: Tak
Informacje dodatkowe: Support for Windows 11 64-bit
Parametry:
Gniazdo procesora:
Socket 1851
Zawiera baterię / akumulator:
Tak
Chipset płyty głównej:
Intel® Z890
