Gniazdo procesora: Socket 1851
Obsługiwane typy procesorów: Intel Core Ultra Processors (series 2)
Uwagi do procesora: Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max 3.0, Intel Turbo Boost Max Technology 3.0 support depends on the CPU types
Format płyty: ATX
BIOS: 256 Mb Flash ROM, UEFI AMI BIOS; WOL by PME, PXE
Chipset płyty głównej: Intel® Z890
Ilość złącz pamięci DDR5: 4
Maksymalna wielkość pamięci: 192 GB
Tryb pracy pamięci RAM: Dual Channel
Standard pamięci: DDR5-8600+ (OC)
Uwagi do pamięci RAM: Support up to 8600+MT/s (OC), Non-ECC, Un-buffered ,Clocked Unbuffered DIMM, Supports Intel® Extreme Memory Profile (XMP) memory module, ASUS Enhanced Memory Profile III (AEMP III), Supports DIMM Fit
Zintegrowany kontroler SATA: Chipset+CPU: 4x SATA III 6Gb/s + 4x M.2
Uwagi do kontrolera SATA: Intel Core Ultra Processors (series 2):, - M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode), - M.2_2 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode), Intel® Z890 Chipset:, - M.2_3 slot (Key M), type 2280/22110 (supports PCIe 4.0 x4 mode), - M.2_4 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 & SATA mode, - 4 x SATA 6Gb/s ports, Intel Rapid Storage Technology supports PCIe RAID 0/1/5/10, SATA RAID 0/1, SATA RAID 0/1/5/10, M.2 slot from CPU only supports RAID 0/1/5
Gniazda karty graficznej: HDMI, DisplayPort, 2x Thunderbolt™ 4 (USB Type-C®)
Uwagi do karty graficznej: Graphics specifications may vary between CPU types. Please refer to, Supports max. 4K@60Hz as specified in DisplayPort 1.4, Supports 4K@60Hz as specified in HDMI 2.1, Supports up to 8K@60Hz x1 with DSC or 4K@60Hz x 2, maximum total, bandwidth up to 23.8Gbps or 16Gbps/16Gbps, for resolution support please, check DisplayPort 2.1 specs, VGA resolution support depends on processors' or graphic cards' resolution
Zintegrowana karta dźwiękowa: Realtek® ALC1220P Codec 7.1-Channel High Definition Audio
Gniazda karty dźwiękowej: Wewnętrzne gniazdo audio przedniego panelu, 5x Audio Jack, Wyjście optyczne S/PDIF
Uwagi do karty dźwiękowej: Impedance sense for front and rear headphone outputs, Internal audio Amplifier to enhance the highest quality sound for headphone, and speakers, Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking, High quality 120 dB SNR stereo playback output and 113 dB SNR recording, Supports up to 32-Bit/192 kHz playback, Audio Shielding, Premium audio capacitors, Dedicated audio PCB layers, Audio cover, Unique de-pop circuit, Due to limitations in HDA bandwidth, 32-Bit/192 kHz is not supported for, 7.1 Surround Sound audio
Złącza PCI Express x16: 2
Złącza PCI Express x4: 1
Złącza PCI Express x1: 2
Uwagi do złącz PCI: Intel Core Ultra Processors (series 2):, - 1 x PCIe 5.0 x16 slot, Intel® Z890 Chipset:, - 1 x PCIe 4.0 x16 slot (supports x4 mode), - 1 x PCIe 4.0 x4 slot, - 2 x PCIe 4.0 x1 slots, Please check the PCIe bifurcation table on the support site, To ensure compatibility of the device installed, please refer to
Port LAN: 1x 2,5 Gigabit LAN Intel®
Uwagi do karty sieciowej: TUF LANGuard
Maksymalna ilość portów USB 2.0: 4
Maksymalna ilość portów USB 3.x: 9
Maksymalna ilość portów USB 4.0: 2
Porty USB na panelu tylnym: 6x USB 3.1 + 2x Thunderbolt 4/USB Type-C
Gniazda USB na płycie głównej: 2x USB 2.0 (4 porty) + 1x USB 3.1 (2 porty) + 1x USB 3.2 Type-C (1 port)
Port Wi-Fi: IEEE 802.11a/b/g/n/ac/ax/be
Port Bluetooth: Bluetooth V5.4
Uwagi do WiFi / BT: 2x2 Wi-Fi 7 (802.11be), Supports 2.4/5/6GHz frequency band, Support Wi-Fi 7 320MHz bandwidth, up to 5.8Gbps transfer rate., Wi-Fi features may vary depending on the operating system, For Windows 11, Wi-Fi 7 will require 24H2 or later version for full, functions, Windows 11 21H2/22H2/23H2 only supports Wi-Fi 6E, For Windows 10, only Wi-Fi 6 is supported
Port PS/2: Brak
Port szeregowy (COM): 1x wewnętrzne gniazdo portu COM
Port równoległy (LPT): Brak
Inne porty i gniazda: 4-pin CPU Fan header, 4-pin CPU OPT Fan header, 4-pin AIO Pump header, 4x 4-pin Chassis Fan headers, 3x Addressable Gen 2 header, Chassis intrusion header, 10-1 pin System Panel header, Thermal Sensor header, Clear CMOS button(s), BIOS FlashBack button , Wi-Fi module with an antenna connector
Gniazdo zasilania: ATX (24-pin) + 2x ATX12V (8-pin)
Wymiary [S x W] (mm): 305 x 244
Opakowanie: BOX
Wyposażenie dodatkowe: 2 x SATA 6Gb/s cables, 1 x ASUS WiFi Q-Antenna, 1 x M.2 Q-Slide package, 2 x M.2 rubber packages, 1 x Screw package for M.2 SSD, 1 x TUF GAMING sticker, 1 x Quick start guide
Zawiera baterię / akumulator: Tak
Informacje dodatkowe: Operating System: Windows 11 (22H2 & later)
Parametry:
Gniazdo procesora:
Socket 1851
Zawiera baterię / akumulator:
Tak
Chipset płyty głównej:
Intel® Z890
